3PCS DC 12V Electronic Temperature Controller Programmable -50 to 110 Degree Celsius Heating/ Cooling Thermostat Control Switch Module NTC Waterproof Sensor Probe Dual Color LED Display Monitor

LED Display:Red: Measuring Temperature; Blue: Setting TemperatureLL: Means the sensor is openHH: Indicates that the temperature exceeds the measurement range of the module--: Indicates that the module is under high temperature protectionProgrammable Thermostat Introductions (Code, Explain, Setting range, Factory setting):P0, Heating/Cooling, H/C, CP1, Return difference, 0.1-30, 2P2, Set limit maximum, +110, 110P3, Set limit minimun, -50, -50P4, Temperature correction, -15 - +15, 0P5, Delay start, 0-10, 0P6, High temperature alarm, -50 - +110, OFFP7, Celsius/Fahrenheit, CS/FH, CSP8, Factory reset, ON-OFF, OFFSpecifications:Operating voltage: DC 12V 200mAPower consumption: ≤ 35 mA (static), ≤ 65 mA (relay close)Temperature sensor type: 10K 0.5% NTCCompatible load: 5A/ 15A 220VAC, 20A 14VDCMeasurement range: -50 to 110 Celsius (-58 to 230 F)Elaboration precision: +/-0.1 CelsiusControl precision: 0.1 CelsiusBacklash precision: 0.1 CelsiusRefresh rate: 0.5 sHigh temperature protection: 0 to 110 degrees Celsius (32 degrees Fahrenheit - 230 degrees Fahrenheit)Module size: 48 x 29 x 32 mm/ 1.89 x 1.14 x 1.26 inchPackage includes:3 x Temperature monitoring controllers

• ❃❃Wide application: the electronic thermostat can be widely applied in intelligent home and industrial equipment, suitable for household appliances, automatic irrigation, office machines, audio, automobiles, aquarium, fish tank etc.
• ❃❃ the measurement temperature is from -50 to 110℃(-58 to 230℉), the control and backlash precision: 0.1 Celsius, the refresh rate: 0.5 s, the module size: 48 x 29 x 32 mm/ 1.89 x 1.14 x 1.26 inch
• ❃❃Temperature controller monitoring instrument, show the measured temperature (red) and set temperature (blue) at the same time. Can be used for cooling/heating control. Operating Voltage: DC12V 200mA
• ❃❃ With a waterproof NTC (10K 0.5%) temperature sensor probe, rogrammable heating/cooling mode, delay start, high temperature alarm, Celsius/Fahrenheit mode, etc.
• ❃❃Package： 3PCS Temperature Controller -50 to 110 Celsius (-58 to 230 F) DC 12V Programmable Heating/Cooling Thermostat Control Switch Module NTC Waterproof Sensor Probe Dual Color LED Display Monitor
• ❃❃Indicator: Lights on, relay closed. Lights out, relay disconnected.
• ❃❃Temperature Setting: Press STC key and the LED will flash. Press STC (+) and C/F (-) key to reach the set temperature value, wait for 3s, and the module will automatically save the parameters and exit.
